Samsung Galaxy Note 10+ UFS ISP PinOut

Note 10+ UFS ISP

Our current topic is the test points of the Galaxy note 10 plus model. These test points are called UFS ISP pinout for short. For what purpose is it used? This method does not require a phone battery. You can remove the battery. In some models that fail as a result of the software, the boot partition of the phone is damaged and the phone does not turn on. For another reason, the phone turns off and does not react in any way. It does not go into download mode or recovery mode. For these situations, you can recover the phone with the isp connection.

To perform this operation, you need jtag boxes. For example, easy jtag, medusa, etc.

Samsung Galaxy Note 10+ UFS ISP PinOut

Samsung-Galaxy-Note-10-UFS-ISP-Pin-Out

Easy Jtag
