Galaxy F02s SM-E025F/DS test point

By knox

November 23, 2021

3473

SM-E025F/DS test point

edl mode is for phones with Qualcomm processors. The Samsung e025f has a Qualcomm Snapdragon 450 processor.

We can put the SM-E025F in edl mode with the following test points.

For this operation, you must first open the back cover of the phone and you need to unscrew the screws on the case.
